Part #: 1-1250

Part Number: 1-1250

Description:

U2BL Poli-Glide 8M/2U/BU

Color:

Blue

Plies:

Nominal OAG:

0.05

+/-

0.01

Fabric:

Polyester

Top Surface:

Smooth

Bottom Surface:

Bare

Compound:

Poly Urethane

Work Tension:

126

Elongation:

Less than 1%

Weight:

0.026

Minimum Pulley Diameter:

0.6

Back Flex Min. Pulley Diameter:

Working Temperature:

-4 to 212

Max. Stocked Width:

78.75

Hardness:

90a

Attributes: Cross Rigid, FDA Compliant, Sliderbed Suitable, Anti-Static, Nosebar Suitable, Oil Resistant

1 of 3

1-1250 Close Up

Features:

1-1250 features an FDA-compliant construction with a non-adhesive top cover designed for clean release and improved hygiene. Its blue surface provides excellent visibility for inspection and detection lines.

The belt offers abrasion resistance, smooth tracking, and reliable edge wear performance under continuous load.

U2BL Poli-Glide 8M/2U/BU is used as an accumulation belt, diverting belt, dough belt, and general-purpose conveyor in food processing, bakery operations, and ingredient handling systems.

Image	Fabrication	Description	Fabrication Type
	A1	Alligator Laced One End	Lacing
	A2	Alligator Laced Both Ends	Lacing
	AV-4	A Section V-Guide - Urethane	V-Guide
	AVN-4	A Section V-Guide Notched - Urethane	V-Guide
	B-1	2 Hole Bucket Punch (B-1)	Hole Punch
	B-2	3 Hole Bucket Punch (B-2)	Hole Punch
	B-3	4 Hole Bucket Punch (B-3)	Hole Punch
	B-4	5 Hole Bucket Punch (B-4)	Hole Punch
	B-5	6 Hole Bucket Punch (B-5)	Hole Punch
	B-6	5 Hole Bucket Punch (B-6)	Hole Punch
	B-7	7 Hole Bucket Punch (B-7)	Hole Punch
	B-8	9 Hole Bucket Punch (B-8)	Hole Punch
	BV-4	B Section V-Guide - Urethane	V-Guide
	BVN-4	B Section V-Guide Notched - Urethane	V-Guide
	C1	Clipper Laced One End	Lacing
	C2	Clipper Laced Both Ends	Lacing
	CSU1	Coated Steel Unibar One End	Lacing
	CSU2	Coated Steel Unibar Both Ends	Lacing
	CV-4	C Section V-Guide - Urethane	V-Guide
	E-E	Endless- Finger Splice	Endless
No image	FSL2	Finger Spiral Laced Both Ends	Lacing
No image	HP	Hole Punch	Hole Punch
	LONG - LW	Longitudinal Splice - LW	Longitudinal
	OC-4	O Section Cleat - Urethane	Cleat
	OV-4	O Section V-Guide - Urethane	V-Guide
	OVN-4	O Section V-Guide Notched - Urethane	V-Guide
	P-1	2 Hole Bucket Punch (P-1)	Hole Punch
	P-2	3 Hole Bucket Punch (P-2)	Hole Punch
	P-3	4 Hole Bucket Punch (P-3)	Hole Punch
	P-4	5 Hole Bucket Punch (P-4)	Hole Punch
	P-5	6 Hole Bucket Punch (P-5)	Hole Punch
	P-7	5 Hole Bucket Punch (P-7)	Hole Punch
	P-8	7 Hole Bucket Punch (P-8)	Hole Punch
	P-9	9 Hole Bucket Punch (P-9)	Hole Punch
	P1	Plastic Rivet Laced One End	Lacing
	P2	Plastic Rivet Laced Both Ends	Lacing
No image	PE-E	Prepared Ends - Finger Splice	Endless
	Perforation	Perforation	Hole Punch
No image	RSSU1	S/S Unibar One End – Recessed	Lacing
No image	RSSU2	S/S Unibar Both Ends – Recessed	Lacing
	S2	Staple Laced Both Ends	Lacing
	SIW410	1-3/16" Sidewall with Base - Urethane	Sidewall
	SIW415	1-9/16" Sidewall with Base - Urethane	Sidewall
	SIW420	2" High Sidewall with Base - Urethane	Sidewall
	SIW430	3" High Sidewall with Base - Urethane	Sidewall
	SL2	Spiral Laced Both Ends	Lacing
	SS1	S/S Staple Laced One End	Lacing
	SS2	S/S Staple Laced Both Ends	Lacing
	SSA1	S/S Alligator Laced One End	Lacing
	SSA2	S/S Alligator Laced Both Ends	Lacing
	SSC1	S/S Clipper Laced One End	Lacing
	SSC2	S/S Clipper Laced Both Ends	Lacing
	SSU1	S/S Unibar One End	Lacing
	SSU2	S/S Unibar Both Ends	Lacing
	TC1-4	1" Tee Cleat - Urethane	Cleat
	TC105-4	1-1/2" Tee Cleat - Urethane	Cleat
	TC2-4	2" Tee Cleat - Urethane	Cleat
	TL105-4	1-1/2" Thin Line Cleat - Urethane	Cleat
	TL205-4	2-1/2" Thin Line Cleat - Urethane	Cleat
